The SR/F delivers 140 ft-lbs of torque and 110 horsepower with the simple twist of a throttle thanks to the class-leading performance and efficiency of Zero’s new ZF75-10 motor and ZF14.4 lithium-ion battery.
Specs
| Range |
PREMIUM |
STANDARD |
| City |
161 miles |
161 miles |
| Highway, 55 mph (89 km/h) |
99 miles |
99 miles |
| Combined |
123 miles |
123 miles |
| Highway, 70 mph (113 km/h) |
82 miles |
82 miles |
| Combined? |
109 miles |
109 miles |
| Motor |
PREMIUM |
STANDARD |
| Peak torque |
140 ft-lb |
140 ft-lb |
| Peak power? |
110 hp (82 kW) @ 5,000 rpm |
110 hp (82 kW) @ 5,000 rpm |
| Top speed (max)? |
124 mph |
124 mph |
| Top speed (sustained)? |
110 mph |
110 mph |
| Type |
Z-Force 75-10 enhanced thermal efficiency, passively air-cooled, interior permanent magnet AC motor |
Z-Force 75-10 enhanced thermal efficiency, passively air-cooled, interior permanent magnet AC motor |
| Controller? |
High efficiency and power dense, 900 Amp, 3-phase AC controller with regenerative deceleration |
High efficiency and power dense, 900 Amp, 3-phase AC controller with regenerative deceleration |
| Power system |
PREMIUM |
STANDARD |
| Power pack |
Z-Force® Li-Ion intelligent integrated |
Z-Force® Li-Ion intelligent integrated |
| Max capacity |
14.4 kWh |
14.4 kWh |
| Nominal capacit |
12.6 kWh |
12.6 kWh |
| Charger type |
6.0 kW, integrated |
3.0 kW, integrated |
| Charge time (standard) |
2.5 hours (100% charged) / 2.0 hours (95% charged) |
4.5 hours (100% charged) / 4.0 hours (95% charged) |
| With 6 kW Rapid Charge option? |
1.5 hours (100% charged) / 1.0 hour (95% charged) |
1.8 hours (100% charged) / 1.3 hours (95% charged) |
| Drivetrain |
PREMIUM |
STANDARD |
| Transmission |
Clutchless direct drive |
Clutchless direct drive |
| Final drive |
90T / 20T, Poly Chain® HTD® Carbon™ belt |
90T / 20T, Poly Chain® HTD® Carbon™ belt |
| Chassis / Suspension / Brakes |
PREMIUM |
STANDARD |
| Front suspension |
Showa 43 mm Big Piston Separate Function forks, with adjustable spring preload, compression and rebound damping |
Showa 43 mm Big Piston Separate Function forks, with adjustable spring preload, compression and rebound damping |
| Rear suspension |
Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping |
Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping |
| Front suspension travel? |
4.72 in |
4.72 in |
| Rear suspension travel? |
5.51 in |
5.51 in |
| Front brakes |
Bosch Advanced MSC, dual J-Juan radial 4-piston calipers with radial master cylinder, 320 x 5 mm discs |
Bosch Advanced MSC, dual J-Juan radial 4-piston calipers with radial master cylinder, 320 x 5 mm discs |
| Rear brakes |
Bosch Advanced MSC, J-Juan single piston floating caliper, 240 x 4.5 mm disc |
Bosch Advanced MSC, J-Juan single piston floating caliper, 240 x 4.5 mm disc |
| Front tire |
Pirelli Diablo Rosso III 120/70-17 |
Pirelli Diablo Rosso III 120/70-17 |
| Rear tire |
Pirelli Diablo Rosso III 180/55-17 |
Pirelli Diablo Rosso III 180/55-17 |
| Front wheel |
3.50 x 17 |
3.50 x 17 |
| Rear wheel |
5.50 x 17 |
5.50 x 17 |
| Dimensions |
PREMIUM |
STANDARD |
| Wheelbase? |
57.1 in |
57.1 in |
| Seat height? |
31.0 in |
31.0 in |
| Accessory, low |
30.3 in |
30.3 in |
| Accessory, tall |
31.9 in |
31.9 in |
| Rake? |
24.5° |
24.5° |
| Trail? |
3.7 in |
3.7 in |
| Weight |
PREMIUM |
STANDARD |
|
| Curb weight |
498 lb |
485 lb |
| Carrying capacity |
502 lb |
515 lb |
| Economy |
PREMIUM |
STANDARD |
| Equivalent fuel economy (city) |
430 MPGe |
430 MPGe |
| Equivalent fuel economy (highway) |
219 MPGe |
219 MPGe |
| Typical cost to recharge |
$1.61 |
$1.61 |
| Pricing |
PREMIUM |
STANDARD |
| MSRP |
$20,995 |
$18,995 |
| Does not include government incentives. Does not include local shipping, applicable taxes, PDI, or road registration fees. |
